BENEFIT FROM OUR EXPERTISE AND WIDE PRODUCT RANGE TO SELECT YOUR SYSTEM MOTORIZATION
Guaranteed calibration, simplified configuration, improved ergonomics, increased speed,…: motorize your optical instrument according to your objectives.
Microvision Instruments motorizes your optical instrument
In order to automate certain applications (counting, granulometry…), to capture images out of the field of view by assembling the images, to configure or record location points to be used or to take several focusing images on the Z axis for samples with considerable depths or heights. Sample’s movements through the joystick and control of the movements and values of the motorized microscope stage directly in your image analysis software improve the ergonomics of your system, as well as the reliability and the efficiency of your controls.
We offer a wide range of microscope accessories for motorization such as motorized XY stages, filter wheels, robots, autofocus systems, shutters or manual displacement stages with magnetic encoder (measurements outside the field of view).
This can be integrated into your existing hardware or supplied as a complete new system. Microvision Instruments will work with you to provide a complete, ergonomic and ready-to-use solution.
- Motorized stage
Displacement range from 75x50mm to 300x300mm driven by control boards or external controllers with joystick - Filter wheels
- Robots
- Autofocus systems
Motorization of the focusing axis to achieve automatic focusing. - Shutters
WE WORK WITH THE BEST MANUFACTURERS TO MOTORIZE YOUR OPTICAL INSTRUMENT
Marzhauser microscope stages feature a flat, ergonomic design and a smooth surface for easy cleaning. Our most common references
Manual microscope stage
EK 75*50
- Travel range: max. 75*50 mm
- Magnetic encoder with 1µm resolution
- Display with USB II interface
Motorized microscope stage SCAN 75*50
- Travel range: 75 x 50 mm
- Max speed: max. 50 mm/s (with 2 mm ball screw pitch)
- Repeatability: < 1 µm (bidirectional)
- Resolution: 0.01 µm (smallest step size)
- 2-phase stepper motor
- Limit switches: light barriers
- Stage opening: 116 x 116 mm
- Alu / anodic coating, black lacquered surface
- Approx. 2.6 kg
Motorized microscope stage
SCAN 100*100
- Travel range: max. 100*100 mm
- Max speed: max. 60 mm/s (with 1 mm ball screw pitch) / max. 120 mm/s (with 2 mm ball screw pitch) / max. 240 mm/s (with 4 mm ball screw pitch)
- Repeatability: < 0,2 µm
- Accuracy < 3 µm
- Resolution: 0.01 µm (smallest step size)
- 2-phase stepper motor
- Limit switches: light barriers
- Alu / anodic coating, black lacquered surface
- Approx. 4,4kg
Contact our experts
Get expert advice to identify the equipment that will meet your needs and budget
Microvision Instruments is supporting you
Image acquisition hardware, image analysis software and service: together we build the effective and long-lasting solution that suits you
Image analysis software developed in-house
Unique service offer to provide you with long-term support
